Denon AVR-X4700H User Manual

Accessories
8
Inserting the batteries
9
Operating range of the remote control unit
9
Features
10
High quality sound
10
High performance
13
Easy operation
17
Part names and functions
18
Front panel
18
Display
22
Rear panel
24
Remote control unit
28
Connections
Speaker installation
32
Connecting speakers
40
Before connecting speakers
40
Speaker configuration and “Amp Assign” settings
44
Connecting 5.1-channel speakers
46
Connecting 7.1-channel speakers
47
Connecting 9.1-channel speakers
51
Connecting 11.1-channel speakers
59
Connecting 7.1-channel speakers: Bi-amp connection of front
speakers
65
Connecting 7.1-channel speakers: Second pair of front speakers
66
Connecting multi-zone speakers
67
Connecting an external power amplifier
71
Connecting a TV
72
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel)
73
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel) / eARC
(Enhanced Audio Return Channel)
74
Connection 3 : TV equipped without an HDMI connector
75
Connecting a playback device
76
Connecting a set-top box (Satellite tuner/cable TV)
77
Connecting a DVD player or Blu-ray Disc player
78
Connecting a player device compatible with the 8K
79
Connecting a video camcorder or game console
80
Connecting a turntable
81
Connecting a USB memory device to the USB port
82
Connecting FM/AM antennas
83
Connecting to a home network (LAN)
85
Wired LAN
85
Wireless LAN
86
Connecting an external control device
87
REMOTE CONTROL jacks
87
TRIGGER OUT jacks
88
Connecting the power cord
89
Contents Connections Playback Settings Tips Appendix
2
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
