Denon AVR-X4700H User Manual

o
Example connection when using one set of height speakers
.
C
FL FR
SBL
SBR
SW
SL SR
FHL FHR
0
Set “Height” - “Height Sp” to “2ch” in the menu when connecting in this
configuration. (v p. 233)
.
FR FL C SR SL
SW
SBR SBL
FHR FHL
HEIGHT 1
z
z
The rear height speakers can be connected instead of the front height speakers.
In this case, set the height speakers to be connected under “Height” - “Layout” in
the menu. (v p. 234)
Contents
Connections Playback Settings Tips Appendix
53
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
