Playback in ZONE2/ZONE3 (Another room)
You can operate this unit to enjoy video and audio in a room (ZONE2 and ZONE3) that is different from the room where this unit is placed (MAIN ZONE).
You can simultaneously play back the same source in both the MAIN ZONE, ZONE2 and ZONE3. You can also play back separate sources in the MAIN
ZONE, ZONE2 and ZONE3.
Connecting ZONE
You can use the following three methods to play back video and audio in
ZONE2 and ZONE3.
0
“Connection through the HDMI ZONE2 connector” (v p. 169)
0
“Connection through the video output connector and speaker output
connector” (v p. 170)
0
“Connection through the video output connector and external power
amplifiers” (v p. 173)
o
Connection 1 : Connection through the HDMI
ZONE2 connector
When a TV is connected to the HDMI ZONE2 OUT connector, you can
play back a video or audio from the device connected to the HDMI 1 –
6 IN connector in ZONE2 (HDMI ZONE2 function).
.
HDMI
ZONE2
HDMI
ZONE2
MAIN ZONE
This unit
0
When a TV is connected to the HDMI ZONE2 OUT connector, and the MAIN
ZONE and ZONE2 are set to the same input source, the MAIN ZONE audio may
be mixed down to 2-channel audio.
Contents Connections Playback Settings Tips Appendix
169
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X4700H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X4700H and is the answer not in the manual?

Denon AVR-X4700H Specifications

General IconGeneral
Channels9.2
HDMI Outputs3
Dolby AtmosYes
DTS:XYes
IMAX EnhancedYes
4K/120Hz Pass-throughYes
8K/60Hz Pass-throughYes
Wi-FiYes
BluetoothYes
HEOS Multi-roomYes
Voice ControlAmazon Alexa, Google Assistant, Apple Siri
Speaker Impedance4-16 ohms
HDR SupportHDR10, HDR10+, Dolby Vision, HLG
eARC SupportYes
Auro-3DYes
Audyssey MultEQ XT32Yes
AirPlay 2Yes
Phono InputYes
Input Sensitivity/Impedance200mV/47k ohms
Analog Audio Inputs6
EthernetYes
Supported Audio FormatsMP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs8
Dimensions17.1 x 15.3 x 6.6 inches
Zone OutputZone 2, Zone 3
Frequency Response10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio102dB
Video Inputs/OutputsComponent (2 in / 1 out)
Digital Audio InputsOptical (2), Coaxial (2)
USB Port1 (Front)
Supported Video Formats4K, 8K
