Denon AVR-X4700H User Manual

Video conversion function
This unit automatically converts the input video signals as shown in the diagram before outputting them to the TV.
0
The MAIN ZONE Video Conversion
function is compatible with the following
formats: NTSC, PAL, SECAM, NTSC4.43,
PAL-N, PAL-M and PAL-60.
0
When component video signals are used,
only 480i and 576i signals are converted to
HDMI signals.
HDMI-compatible TV
Output
(MONITOR OUT)
Input (IN)
Video signal Video signal
Component
video signal
HDMI signal
Output
Video device
This unit
HDMI-incompatible TV
HDMI signal
HDMI connector HDMI connector HDMI connector HDMI connector
Component
video signal
Component video
connectors
Component
video connectors
Component video
connectors
Component video
connectors
Video connector Video connector Video connector Video connector
Contents
Connections Playback Settings Tips Appendix
314
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
