Sound mode that can be selected for each input signal
0
The following sound modes can be selected using the MOVIE, MUSIC and GAME buttons.
0
Adjust the sound field effect with the menu “Surround Parameter” to enjoy surround sound the way you like it. (v p. 183)
.
Stereo
SSS
Dolby Surround
SSS
DTS Neural:X z2 SSS
DTS Virtual:X z3z4 SSS
Auro-3D z5 SSS
Auro-2D Surround z6 SSS
Multi Ch Stereo
SSS
Mono Movie
S
Rock Arena
S
Jazz Club
S
Matrix
S
Video Game
S
Virtual
SSS
2-channel z1
GAME button
MUSIC button
MOVIE buttonSound mode
Input signal
z1
2-channel also includes analog input.
z2
This mode plays back 2-channel sources in 5.1, 7.1, 9.1 or 11.1-channel playback. It cannot be selected when headphones are used or when the speaker configuration is
front speakers only.
z3
It cannot be selected when headphones are used, or when a speaker configuration with any height speakers is used.
z4
It cannot be selected when the input signal is Dolby Digital, Dolby Digital Plus, Dolby TrueHD or Dolby Atmos.
z5
It cannot be selected when headphones are used, or when a speaker configuration without front height or front Dolby Atmos Enabled speakers is used.
z6
It cannot be selected when headphones are used, or when only front speakers are used.
Contents Connections Playback Settings Tips Appendix
150
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X4700H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X4700H and is the answer not in the manual?

Denon AVR-X4700H Specifications

General IconGeneral
Channels9.2
HDMI Outputs3
Dolby AtmosYes
DTS:XYes
IMAX EnhancedYes
4K/120Hz Pass-throughYes
8K/60Hz Pass-throughYes
Wi-FiYes
BluetoothYes
HEOS Multi-roomYes
Voice ControlAmazon Alexa, Google Assistant, Apple Siri
Speaker Impedance4-16 ohms
HDR SupportHDR10, HDR10+, Dolby Vision, HLG
eARC SupportYes
Auro-3DYes
Audyssey MultEQ XT32Yes
AirPlay 2Yes
Phono InputYes
Input Sensitivity/Impedance200mV/47k ohms
Analog Audio Inputs6
EthernetYes
Supported Audio FormatsMP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs8
Dimensions17.1 x 15.3 x 6.6 inches
Zone OutputZone 2, Zone 3
Frequency Response10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio102dB
Video Inputs/OutputsComponent (2 in / 1 out)
Digital Audio InputsOptical (2), Coaxial (2)
USB Port1 (Front)
Supported Video Formats4K, 8K
