Denon AVR-X4700H User Manual

Initializing registered preset codes
1
Press and hold down MAIN and OPTION until the DEV.,
TV and AVR indicators on the remote are flashing
green, then release.
Specifying the operating zone with the
remote control
To prevent accidental misuse, you can set the zone for which the remote
control unit is used.
1
Press and hold down either MAIN, Z2 or Z3 and SETUP
at the same time until the DEV., TV and AVR indicators
flash green.
MAIN: When only using MAIN ZONE
Z2: When using MAIN ZONE and ZONE2
Z3
(Default):
When using MAIN ZONE, ZONE2 and
ZONE3
Resetting the remote control unit
All the settings are restored to their defaults.
1
Press and hold down DEVICE MENU until the DEV., TV
and AVR indicators on the remote are flashing green,
then release.
2
Press 9, 8 and 1, in that order.
The DEV., TV and AVR indicators flash twice.
All the settings are restored to their defaults.
Contents Connections Playback Settings Tips Appendix
282
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
