Denon AVR-X4700H User Manual

.
DTS:X
DTS:X
SSS
DTS:X MSTR
SSS
DTS:X + Virtual:X z3 SSS
IMAX DTS
IMAX DTS SSS
IMAX DTS + Neural:X z8z12 SSS
IMAX DTS + Virtual:X z3z12 SSS
IMAX DTS:X
IMAX DTS:X SSS
IMAX DTS:X + Virtual:X z3z12 SSS
Multi Ch In
SSS
Multi Ch In 7.1 z8 SSS
Multi In + Dolby Surround z8 SSS
Multi In + Neural:X z8 SSS
Multi In + Virtual:X z3 SSS
z8z12
z8z12
Multi-channel z7
GAME button
MUSIC button
MOVIE button
Sound modeInput signal
PCM multi-channel
z3
It cannot be selected when headphones are used, or when a speaker configuration with any height speakers is used.
z7
The sound mode that can be selected differs depending on the audio format of the input signal and the number of channels.
z8
This cannot be selected when headphones are used.
z12 Selectable when “Surround Parameter” - “IMAX” is set to “Auto” in the menu. When “IMAX” is set to “Off”, playback is normal DTS or DTS:X. (v p. 186)
Contents
Connections Playback Settings Tips Appendix
153
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
