Denon AVR-X4700H User Manual

o
Example connection when using two sets of
Dolby Atmos Enabled speakers
.
C
SBL
SBR
SW
SL SR
FL
FR
FDL FDR
SDL SDR
0
Set “Height” - “Dolby Sp” to “4ch” in the menu when connecting in this
configuration. (v p. 233)
.
SBR SBL
FR FL C SR SL
SW
SDR SDL
HEIGHT 2
z
Power amplifier
FDR FDL
HEIGHT 1
z
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v p. 63)
0
You can connect the external power amplifier to the Front channel instead of the
Height2 channel. Use the “Pre-out” setting in the menu to set the channel
connected to the external power amplifier. (v p. 237)
Contents Connections Playback Settings Tips Appendix
61
Front panel Display Rear panel Remote Index

Denon AVR-X4700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Speaker Impedance	4-16 ohms
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Auro-3D	Yes
Audyssey MultEQ XT32	Yes
AirPlay 2	Yes
Phono Input	Yes
Input Sensitivity/Impedance	200mV/47k ohms
Analog Audio Inputs	6
Ethernet	Yes
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Power Output	125W per channel (8 ohms, 20Hz-20kHz, THD: 0.05%, 2ch driven)
HDMI Inputs	8
Dimensions	17.1 x 15.3 x 6.6 inches
Zone Output	Zone 2, Zone 3
Frequency Response	10Hz-100kHz (+1, -3 dB, Direct Mode)
Total Harmonic Distortion	0.05% (20Hz-20kHz, 8 ohms)
Signal-to-Noise Ratio	102dB
Video Inputs/Outputs	Component (2 in / 1 out)
Digital Audio Inputs	Optical (2), Coaxial (2)
USB Port	1 (Front)
Supported Video Formats	4K, 8K
