Denon AVR-X5200W Service Manual

YES
YES
YES
YES
Check the TV.
(12) Does the TV support HDCP?
(14) Is HDMI input set on the TV?
(15) Are a picture and sound output when a different TV is used?
Check the unit.
Check the rmware.
Is "IP SCALER ERR" displayed?
(See 21 page)
(13) Does the TV support 1080P/4K?
Use a TV that supports HDCP. Computer monitors can-
not be used.
Check the instruction manual of the TV and check the
input setting.
The TV is faulty.
•Check the circuits around the IP SCALER (U2800,
DIGITAL PCB) and DDR2 (U3000/U3001).
If there appear to be no problems, U2800 or U3000/
U3001 is faulty.
If the TV does not support 1080P/4K, a picture cannot be
output even if the Blu-ray/DVD player is set to 1080P/4K.
NO
NO
NO
YES
NO
See "AVR-X5200W_HDMI Rx-Tx Failure Detection Procedure Manual
ver_1.00" of SDI.
NO
NO
(11) Are a picture and sound output when a different Blu-ray/DVD
player is used?
The Blu-ray/DVD player is faulty.
YES
103

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
