Denon AVR-X5200W Service Manual

4. AUDIO
4.1. AUDIO CHECK
No audio output See"Audio Check PATH" (114 page).
Check the ANALOG AUDIO
BLOCK
Check the DIGITAL AUDIO
BLOCK
Check the ADC BLOCK
Check the HDMI BLOCK
Check for other causes
Check the HDMI BLOCK
Check the DIGITAL AUDIO BLOCK
CHECK1 INPUT SURROND MODE SOURCE
Audio output OK? ANALOG 2CH DIRECT ANALOG
CHECK2 INPUT SURROND MODE SOURCE
Audio output OK? COAX or OPT Don't care
Legacy
(PCM or DolbyDigital or dts…)
CHECK4 INPUT SURROND MODE SOURCE
Audio output OK? HDMI Don't care
Legacy
(PCM2ch or DolbyDigital or dts…)
CHECK6 INPUT Connect
AVR's (connected in HDMI) audio out-
put OK?
HDMI This unit's HDMI OUT → Other AVR's HDMI IN
Setting SURROND MODE SOURCE
CEC STANDBY Don't care HBR audio (DolbyTrueHD or dtsHD MA)
CHECK5 INPUT SURROND MODE SOURCE
Audio output OK? HDMI Don't care
HBR audio
(DolbyTrueHD or dtsHD MA)
CHECK3 INPUT SURROND MODE SOURCE
Audio output OK? ANALOG 2CH MULTICH STEREO ANALOG
YES
YES
YES
YES
YES
NO
NO
YES (DIGITAL AUDIO BLOCK is OK)
NO
NO
NO
NO
104

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
