Denon AVR-X5200W Service Manual

NO
NO
NO
Is U6503 (TOP267EG) damaged?
Are there the damage in U6503 and
D6503 / C6506?
Repair the short circuited area by the
soldering of the PCB.
Check the damage of each part.
Replace the damaged part.
Replace the damaged part.
Has a fuse (F70) broken?
Are there any short circuits caused by
the soldering of the PCB?
Are any parts damaged?
Replace the U6503 (TOP267EG) and
D6503.
DC 5V is not output.
YES
YES
YES
YES
YES
YES
6. SMPS
112

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
