5. BACK PANEL ASSY
Proceeding : TOP COVER → FRONT PANEL ASSY → RADIATOR ASSY → SMPS ASSY → POWER TRANS
→ BACK PANEL ASSY
(1) Remove the screws.
Shooting
direction: D
Shooting
direction: C
↑Shooting direction: A↑
17
