Denon AVR-X5200W Service Manual

4. Remote ID Setup Mode
4.1. Actions
This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are used in the same
room.
4.2. Starting up
Hold down buttons "STATUS" and "ZONE3 SOURCE" at the same time and press the power button to turn on the power.
Select the "6. REMOTE ID" using the button "CURSOR
f
", and press the button "ENTER" to commit the selection.
4.3. Operations
(1) When Remote ID Setup mode is started, the following is displayed.
FLD
L1
L2
R E M O T E I D ?
(2) Press the "
QUICK SELECT 1 - 4" button that corresponds to the number you want to set.
Button Display
QUICK SELECT 1
L2
R E M O T E I D 1
QUICK SELECT 2
L2
R E M O T E I D 2
QUICK SELECT 3
L2
R E M O T E I D 3
QUICK SELECT 4
L2
R E M O T E I D 4
(3) Press the power button to turn off the power.
(4) Press the power button to turn on the power.
b
Only "
QUICK SELECT 1 - 4" and the POWER button on the unit can be used in Remote ID Setup Mode.
4.4. Setting the Remote coutrol unit
(1) Press and hold "
DEVICE MENU" button for at least 3 seconds "DEV.", "TU" and "AVR" indicators ash time.
(2) Press the "
MAIN" button.
The "DEV.", "TU" and "AVR" indicators ash twice.
(3) Press the "
1", "2", "3" or "4" button.
The "DEV.", "TU" and "AVR" indicators ash twice.
NOTE:
If the ID of the unit and remote control do not match, "AVAMP
z
" appears on the display of the unit when the remote
control is used (*: own remote control ID).
74

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
