Denon AVR-X5200W Service Manual

Pin Pin Name Symbol I/O
Pull up/
down
LvCnv STBY STOP
CEC
STBY
Function
17 P86 (CEC POWER2) O - - L L H Reserve (CEC POWER2 control)
18 P85
REMOTE
POWER(232C)
O - - L L L
232C POWER SUPPLY (REMOTE
3.3V) control pin.(ON: H)
19 RES# RESET I - - - - - Reset input (reset: L)
20 XTAL XTAL I - - - - - Clock input
21 VSS VSS - - - - - - GND
22 EXTAL EXTAL - - - - - - Clock output
23 VCC VCC - - - - - - +3.3V
24 NMI NMI I M3VPu - - - - NC
25
P34/IRQ4-A/PO12/
TIOCA1
BDOWN I - - I I I
Power failure detection pin(Power
failure:L)
26
P33/IRQ3-A/PO11/
TIOCC0/TIOCD0/
TCLKB-A
PLDAERR I - - L L L PLD ERROR detection pin
27
P32/IRQ2-A/PO10/
TIOCC0/TCLKA-A
NC O - - L O L Unused
28
P31/IRQ1-A/PO9/
TIOCA0/TIOCB0
ADV8003 INT1 I
- - I I I
HDMI transmitter / OSD (ADV8003)
INT1 Input pin
29
P30/IRQ0-A/PO8/
TIOCA0
RC IN I - - I I I Remote control signal input pin
30
P27/PO7/TIOCA5/
TIOCB5/SCK1
HDMI A SEL O - - L L L
TC74VHCT244AFT control pin.
(Control the HDMI Audio input. H : DSP
signal path / L : HDMI Rx -> Tx )
31
P26/PO6/TIOCA5/
TMO1/TxD1
NC O - - L L L Unused
32
P25/PO5/TIOCA4/
TMCI1/RxD1
NC O - - L L L Unused
33
P24/PO4/TIOCA4/
TIOCB4/TMRI1
TU RST O SW3VPu - L L L TUNER RESET pin (E3 model)
34
P23/PO3/TIOCC3/
TIOCD3
E RESET O N3VPu - L L L
ETHERNET RESET control pin
(DM860)
35
P22/PO2/TIOCC3/
TMO0/SCK0
E POWER O -/- - L L L
ETHERNET POWER SUPPLY
(NET3.3V) control pin.(ON:H)
36
P21/PO1/TIOCA3/
TMCI0/RxD0
E_RXDMIEO I -/- - I I I
ETHERNET communication control pin
(DM860)
37
P20/PO0/TIOCA3/
TIOCB3/TMRI0/TxD0
E_TXDMOEI O -/- - L L L
ETHERNET communication control pin
(DM860)
38
P17/IRQ7-B/
TCLKD-B/TxD3/
SCL0/ADTRG1#
TU SCLK O - - L L L TUNER control pin
39 PLLVCC PLLVCC - - - - - - +3.3V
40
P16/IRQ6-B/
TCLKC-B/RxD3/
SDA0
TU SDIO I_O - - L L L TUNER control pin
41 PLLVSS PLLVSS - - - - - - GND
42
P15/IRQ5-B/
TCLKB-B/SCK3/
SCL1
HSCL (400k) O CEC3VPu - L L L
VIDEO I2C Control for - HDMI SW
(ADV3002) / HDMI RX , A to H
Decoder (ADV7850) / HDMI ip Scaler ,
TX (ADV8003)
43
P14/IRQ4-B/
TCLKA-B/SDA1
HSDA (400k) I_O CEC3VPu - L L L
VIDEO I2C Control for - HDMI SW
(ADV3002) / HDMI RX , A to H
Decoder (ADV7850) / HDMI ip Scaler ,
TX (ADV8003)
44
P13/IRQ3-B/TxD2/
ADTRG0#
ADV8003 SPI MO O - - L L L
OSD control pin (ADV8002 or
ADV8003)
45 P12/IRQ2-B/RxD2 ADV8003 SPI MI I - - L L L
OSD control pin (ADV8002 or
ADV8003)
46 P11/IRQ1-B/SCK2 ADV8003 SPI CLK O - - L L L
OSD control pin (ADV8002 or
ADV8003)
47 P10/IRQ0-B ADV8003 SPI CS O - - L L L
OSD control pin (ADV8002 or
ADV8003)
48
P37/PO15/TIOCA2/
TIOCB2/TCLKD-A
EEPROM SDA I_O M3VPu - I I I EEPROM control pin
49 P36/PO14/TIOCA2 EEPROM SCL O M3VPu - I I I EEPROM control pin
50
P35/PO13/TIOCA1/
TIOCB1/TCLKC-A
ADV7850 RST O - - L L L
HDMI RX , A to H Decoder (ADV7850)
RESET control pin
51 P84 CEC_OUT O -
- L L - CEC-D signal output pin
52
P57/WAIT#/
TRDATA3
ADV3002 RST O SW3VPu - L L L
HDMI switcher RESET control pin
(ADV3002)
53 P56/TRDATA2 E SPI MOEI O N3VPu - L L L
ETHERNET communication control pin
(DM860)
54 P55/TRDATA1 ADV8003 RST O SW3VPu - L L L
HDMI Tx/ip Scaler/OSD RESET control
pin (ADV8003)
171

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
