Denon AVR-X5200W Service Manual

Pin Pin Name Symbol I/O
Pull up/
down
LvCnv STBY STOP
CEC
STBY
Function
139 P41/IRQ9-B/AN1 HDMI IN 5V SET I - - I I I
HDMI INPUT 5V (for EDID / HOT
PLUG) detection pin
140 AVSS AVSS - - - - - - GND
141 P40/IRQ8-B/AN0 CEC_IN I SW3VPu - I I I CEC-D signal input pin
142 VREF VREF - - - - - -
Reference voltage (+3.3V) input pin for
A/D port
143 AVCC AVCC - - - - - - +3.3V
144
P05/IRQ13-A/TMO3/
RxD4/TCK
NC I M3VPu - I I I NC
174

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
