Denon AVR-X5200W Service Manual

FRONT SPK
FRONT SPK PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D6001,6002 20305004300AS KBJ2506 20305004300AS 2 *
D6003-6011 00D2760794900 KDS160-RTK/P 00D2760794900 9
D6012 00D2760683943 UDZS3.6B-TE17 00D2760683943 1
D6013-6022 00D2760794900 KDS160-RTK/P 00D2760794900 10
D6023 00D2760683943 UDZS3.6B-TE17 00D2760683943 1
D6024,6025 00D2760794900 KDS160-RTK/P 00D2760794900 2
D6201-6225 20305002730AS 1N4003(HOMI) 20305002730AS 25
D6228,6229 00D2760798948 UDZS8.2B-TE17 00D2760798948 2
D6230,6231 00D2760750902 RB521S-30TE61 +REF 00D2760750902 2
D6232,6233 20305002730AS 1N4003(HOMI) 20305002730AS 2
D6238,6239 00D2760750902 RB521S-30TE61 +REF 00D2760750902 2
D6401 26301009410AS PVBWR-5A2M(WHITE/RED LED) E3 26301009410AS 1 *
D6401 26301006510AS BL-BJEGJ204L E2,E1C 26301006510AS 1
D6406 00D2760798948 UDZS8.2B-TE17 00D2760798948 1
D6407 20305002730AS 1N4003(HOMI) 20305002730AS 1
D6408 263010032409S SIR-341STA49 263010032409S 1
D6410,6411 00D2760798935 UDZS20B-TE17 00D2760798935 2
D6414-6416 00D2760683930 UDZS5.1B-TE17 +C 00D2760683930 3
Q6001 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q6003 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q6005 00D2710318909 2N5401S-RTK/P 00D2710318909 1
Q6006 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q6008 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q6010-6014 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 5
Q6015 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q6016,6017 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 2
Q6018 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q6019,6020 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 2
Q6021 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q6022 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6024 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q6026 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6027 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q6030 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6031 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q6034 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q6036 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6037 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q6040 21385001950AS 2SC5810 21385001950AS 1
Q6042 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6044 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6046 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6048 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6050 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6052 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6054 21685002450AS KRC105S-RTK(2.2K-47K) 21685002450AS 1 *
Q6201 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q6202 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q6203 21205001820AS KTA1046 21205001820AS 1
Q6204 21405001920AS KTC2026 21405001920AS 1
Q6401 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q6402,6403 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 2
Q6404 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902
1
Q6405 21385001950AS
2SC5810 21385001950AS 1
Q6406 00D2690191903 KRA104S-RTK/P (47K-47K) 00D2690191903 1
Q6408 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
U6001 23281004150AS NJM8080G 23281004150AS 1
U6201 00D2630801004 NJM7812FA(S) 00D2630801004 1
U6202 00D2630809006 NJM7805FA(S) 00D2630809006 1
U6203 00D2631048002 BA033T 00D2631048002 1
U6204 00D2630554005 NJM7905FA 00D2630554005 1
U6401 262010009000S R34FS8A 262010009000S 1
U6403,6404 23281004150AS NJM8080G 23281004150AS 2
RESISTOR GROUP
R6001 nsp RM73B--823JT +1608 00D2472012909 1
R6003 nsp RM73B--823JT +1608 00D2472012909 1
R6005 nsp RM73B--0R0KT +1608 00D2472018903 1
R6007 nsp RM73B--224JT +1608 00D2472013908 1
R6009 nsp RM73B--0R0KT +1608 00D2472018903 1
R6011 00MGG0510116X 100 OHM +- 5% 1/6W 00MGG0510116X 1
R6012 nsp RM73B--224JT +1608 00D2472013908 1
R6014 nsp RM73B--0R0KT +1608 00D2472018903 1
R6016 00MGG0504716X 4.7 OHM +- 5% 1/6W 00MGG0504716X 1
R6018,6019 nsp RM73B--103JT +1608 00D2472009983 2
R6020 nsp RM73B--332JT +1608 00D2472008968 1
R6021 nsp RM73B--223JT +1608 00D2472010969 1
R6022 nsp RM73B--153JT +1608 00D2472010927 1
R6023-6029 nsp RM73B--103JT +1608 00D2472009983 7
R6030,6031 nsp RM73B--223JT +1608 00D2472010969 2
R6032 nsp RM73B--104JT +1608 00D2472012925 1
R6033-6037 nsp RM73B--223JT +1608 00D2472010969 5
R6038 nsp RM73B--153JT +1608 00D2472010927 1
R6039 nsp RM73B--223JT +1608 00D2472010969 1
R6040 nsp RM73B--104JT +1608 00D2472012925 1
R6041-6049 nsp RM73B--474JT +1608 00D2472013982 9
R6050 nsp RM73B--153JT +1608 00D2472010927 1
R6055 nsp RM73B--104JT +1608 00D2472012925 1
R6060 12905006810AS RGC502T02 12905006810AS 1
R6061 nsp RM73B--103JT +1608 00D2472009983 1
R6062 nsp RM73B--101JT +1608 00D2472005903 1
R6063 nsp RM73B--0R0KT +2125 00D2470018905 1
R6064 nsp RM73B--0R0KT +1608 00D2472018903 1
R6065 nsp RM73B--0R0KT +2125 00D2470018905 1
R6067 nsp RM73B--0R0KT +2125 00D2470018905 1
R6068 nsp RM73B--153JT +1608 00D2472010927 1
R6070 nsp RM73B--0R0KT +2125 00D2470018905 1
R6071 nsp RM73B--473JT +1608 00D2472011942 1
R6073-6075 nsp RM73B--0R0KT +2125 00D2470018905 3
1

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
