Denon AVR-X5200W

AUDIO VIDEO
AUDIO VIDEO PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D3501-3515 00D2760794900 KDS160-RTK/P 00D2760794900 15
D5559-5561 251310004507S CG0603MLC-12LE 251310004507S 3
Q3501 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3502 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3503 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3504 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3505 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3506 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3507 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3508 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3509 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3510 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3511 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3512 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3513 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3514 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3515 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3516 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3517 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3518 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3519 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3520 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3521 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3522 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3523 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3524 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3525 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3526 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 1
Q3527 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q3528,3529 21585001550AS KRA105S-RTK/P(2.2K-47K) 21585001550AS 2
Q3530 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q5201 213850009503S 2SC4617EBTLR 213850009503S 1
Q5501 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q5502 00D2690193901 KRC104S-RTK/P (47K-47K) 00D2690193901 1
U3001-3004 23381001450AS CD74HC4094PWR 23381001450AS 4 *
U3005 23281004150AS NJM8080G E3 23281004150AS 1
U3201,3202 235810045600S R2A15220FP 235810045600S 2
U3203,3204 00D2623727904 NJW1194V-TE1 00D2623727904 2
U3205-3210 23281004150AS NJM8080G 23281004150AS 6
U3501 00D2630995004 NJM4556AD +T 00D2630995004 1
U3703 235810046603S AVDM-2000 235810046603S 1
U5001 236810086505S AK5358BET 236810086505S 1
U5002,5003 23681012050AS PCM5100PWR 23681012050AS 2
U5004 00D2631047906 NJM2115M-TE1 +C 00D2631047906 1
U5201,5202 236810082503S PCM1690 236810082503S 2
U5203-5209 23281004150AS NJM8080G 23281004150AS 7
U5501 236810064604S AD8195ACPZ 236810064604S 1
RESISTOR GROUP
R3001-3004 nsp RM73B--0R0KT +1608 00D2472018903 4
R3026 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R3027,3028 nsp RM73B--0R0KT +1608 00D2472018903 2
R3030 nsp RM73B--750DT(1608) 00D2472032905
1
R3031-3034 nsp
RM73B--0R0KT +1608 00D2472018903 4
R3102 nsp RM73B--0R0KT +1608 E3 00D2472018903 1
R3104 nsp RM73B--100JT +1608 E3 00D2472002964 1
R3106 nsp RM73B--100JT +1608 E3 00D2472002964 1
R3111,3112 nsp RM73B--393JT +1608 E3 00D2472011926 2
R3113,3114 nsp RM73B--243JT +1608 E3 00D2472010972 2
R3115,3116 nsp RM73B--104JT +1608 E3 00D2472012925 2
R3117 nsp RM73B--0R0KT +1608 E3 00D2472018903 1
R3119,3120 nsp RM73B--102JT +1608 E3 00D2472007943 2
R3121,3122 nsp RM73B--153JT +1608 E3 00D2472010927 2
R3134-3137 nsp RM73B--330JT +1608 E2,E1C 00D2472003989 4
R3128,3129 nsp RM73B--102JT +1608 E2,E1C 00D2472007943 2
R3126,3127 nsp RM73B--104JT +1608 E2,E1C 00D2472012925 2
R3130,3131 nsp RM73B--104JT +1608 E2,E1C 00D2472012925 2
R3132,3133 nsp RM73B--823JT +1608 E2,E1C 00D2472012909 2
R3138 nsp RM73B--222JT +1608 E2,E1C 00D2472008926 1
R3201-3212 nsp RM73B--471JT +1608 00D2472006960 12
R3223-3234 nsp RM73B--824JT +1608 00D2472014949 12
R3237-3244 nsp RM73B--824JT +1608 00D2472014949 8
R3267 nsp RM73B--473JT +1608 00D2472011942 1
R3270-3275 nsp RM73B--470JT +1608 00D2472004920 6
R3276,3277 nsp RM73B--473JT +1608 00D2472011942 2
R3278-3283 nsp RM73B--470JT +1608 00D2472004920 6
R3284-3288 nsp RM73B--473JT +1608 00D2472011942 5
R3289,3290 nsp RM73B--470JT +1608 00D2472004920 2
R3291,3292 nsp RM73B--473JT +1608 00D2472011942 2
R3293,3294 nsp RM73B--470JT +1608 00D2472004920 2
R3295 nsp RM73B--473JT +1608 00D2472011942 1
R3296,3297 nsp RM73B--470JT +1608 00D2472004920 2
R3298 nsp RM73B--0R0KT +1608 00D2472018903 1
R3301-3304 nsp RM73B--474JT +1608 00D2472013982 4
R3305-3308 nsp RM73B--154JT +1608 00D2472012967 4
R3309-3312 nsp RM73B--334JT +1608 00D2472013940 4
R3313-3316 nsp RM73B--101JT +1608 00D2472005903 4
R3317-3320 nsp RM73B--104JT +1608 00D2472012925 4
R3321-3328 nsp RM73B--393JT +1608 00D2472011926 8
R3329-3332 nsp RM73B--223JT +1608 00D2472010969 4
R3333-3340 nsp RM73B--472JT (1608) +1608 00D2472009909 8
R3341-3344 nsp RM73B--470JT +1608 00D2472004920 4
R3345-3348 nsp RM73B--104JT +1608 00D2472012925 4
R3349-3352 nsp RM73B--101JT +1608 00D2472005903 4
R3353-3356 nsp RM73B--472JT (1608) +1608 00D2472009909 4
R3357-3364 nsp RM73B--104JT +1608 00D2472012925 8
R3371-3376 nsp MNR04=473(1005X4) 126210009591S 6
R3378-3383 nsp PRB3T4=0R0(1005X4) 126250001502S 6
R3386 nsp MNR04=473(1005X4) 126210009591S 1
