Denon AVR-X5200W

DIGITAL
DIGITAL PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D2448 00D2760750902 RB521S-30TE61 +REF 00D2760750902 1
D3404 00D2760794900 KDS160-RTK/P 00D2760794900 1
D3413 25131010150AS NV73A1JTTE8.2 25131010150AS 1 *
D5001-5003 00D2760794900 KDS160-RTK/P 00D2760794900 3
Q1001,1002 00D2690144905 DTC114YKA-T146 +C 00D2690144905 2
Q1906 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 1
Q1907 00MBA2000199Y KRC404E-RTK KEC STANDARD 00MBA2000199Y 1
Q1908 211850008504S 2SA2018TL 211850008504S 1
Q1909 00D2750110905 HN1K02FU-TE85L 00D2750110905 1
Q2101,2102 213850009503S 2SC4617EBTLR 213850009503S 2
Q2103 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 1
Q2105 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 1
Q2400-2402 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 3
Q2404-2406 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 3
Q2408-2410 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 3
Q2600-2607 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 8
Q3402 00D2740195901 2SD2114KT196 +C 00D2740195901 1
Q3601 211850008504S 2SA2018TL 211850008504S 1
Q3603,3604 00MBA2000199Y KRC404E-RTK KEC STANDARD 00MBA2000199Y 2
Q3605 00D2757001907 FDC608PZ 00D2757001907 1
Q5001 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 1
Q5002 211850008504S 2SA2018TL 211850008504S 1
Q5003 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 1
Q5004 00D2757001907 FDC608PZ 00D2757001907 1
Q5005 213850009503S 2SC4617EBTLR 213850009503S 1
Q5006-5008 00MBA2000399Y KRC402E-RTK KEC 00MBA2000399Y 3
Q5009 211850008504S 2SA2018TL 211850008504S 1
U0101 24581010060AD ADSP-21487KSWZ-4B(3071-1) 24581010060AD 1 *
U0102 - MX25L1606EM2I-12G 24681009160AS 1 *
┗U0102
9R2481025500S
DSP1 ROM SUB ASS
Y
-1*
U0103 24681008960AS A3V56S40GTP-60 24681008960AS 1
U0201 24581010061AD ADSP-21487KSWZ-4B(3071-2) 24581010061AD 1 *
U0202 - MX25L1606EM2I-12G 24681009160AS 1 *
┗U0202
9R2481025600S
DSP2 ROM SUB ASS
Y
-1*2
U0203 24681008960AS A3V56S40GTP-60 24681008960AS 1
U0301 24581010062AD ADSP-21487KSWZ-4B(3071-3) 24581010062AD 1 *
U0302 - MX25L1606EM2I-12G 24681009160AS 1 *
┗U0302
9R2481025700S
DSP3 ROM SUB ASS
Y
-1*
U0303 24681008960AS A3V56S40GTP-60 24681008960AS 1
U0401 24581010063AD ADSP-21487KSWZ-4B(3071-4) 24581010063AD 1 *
U0402 - MX25L1606EM2I-12G 24681009160AS 1 *
┗U0402
9R2481030200S
DSP4 ROM SUB ASS
Y
-1*
U0403 24681008960AS A3V56S40GTP-60 24681008960AS 1
U0602 nsp MX25L25635FMI-10G 24681009260AS 1 * 2
U0603 23681012650AS NCP380HMU21AATBG 23681012650AS 1
U0607 23671011050AS MFI337S3959 IPOD COPROCESSOR 2.0C CLASS6 23671011050AS 1
U0608-0611 231810089509S EX3AV 231810089509S 4
U1000 23681014050AS PCM9211 23681014050AS 1
U1004,1005 23681016350AS LC89091JA 23681016350AS 2 *
U1201 23681011960AS 5M570ZF256C5N 23681011960AS 1
U1202 23171011751AS NJM2845DL1-18 23171011751AS 1
U1203 236810083506S CS2100-10-CZZR 236810083506S 1
U1205 236810012504S FCXO-05B(24.576MHz) 236810012504S 1
U1206 14181010150AS TXC 8W(25.000MHZ) 14181010150AS 1 *
U1901,1902 231810089509S EX3AV 231810089509S 2
U1903 00D2623436907 TC74VHC244FT 00D2623436907 1
U1904 23381001250AS SN74AHCU04PWR 23381001250AS 1 *
U1905 23171011750AS NJM2845DL1-33 23171011750AS 1
U1906 231810089509S EX3AV 231810089509S 1
U2000 23681012760AS ADV7850KBCZ-5 23681012760AS 1
U2101 - R5F5210ABDFP 24181004160AS 1
┗U2101
9R2431019900S
SUB CPU SUB ASSY
(
AVRX5200
)
-1*
U2400 23381001350AS SN74CBT3251PWR 23381001350AS 1 *
U2401 23681015960AS MN8647771 23681015960AS 1 *
U2601 23681015960AS MN8647771 23681015960AS 1 *
U2800 23681016160AS AD55/058Z-0(ADV8003-8B) 23681016160AS 1
U2801 - MX25L12835FMI-10G 24681008460AS 1
┗U2801
9R2481025900S
GUI ROM SUB ASSY
(
AVRX5200E3/E2
)
E3,E2 - 1 *
┗U2801
9R2481025901S
GUI ROM SUB ASSY
(
AVRX5200E1C
)
E1C - 1 *
U3000,3001 24681020160AS A3R12E40CBF-8E 24681020160AS 2
U3200 26381020260AS EPM570F256C4N 26381020260AS 1 *
U3401 23681015960AS MN8647771 23681015960AS 1 *
U3600 231810089509S EX3AV 231810089509S 1
U3601 23681013550AS NCP380HMUAJAATBG 23681013550AS 1
U3603-3606 231810089509S EX3AV 231810089509S 4
U5001 - R5F56108VNFP 24181003860AS 1 *
┗U5001
9R2431019800S
MAIN CPU SUB ASSY
(
AVRX5200
)
E3, E2 - 1 *
┗U5001
9R2431019801S
MAIN CPU SUB ASSY
(
AVRX5200W/E1C
)
E1C - 1 * 2
U5002 24681009350AS R1EX24256BSAS0I 24681009350AS 1 *
U5003 23981007450AS PST8448(SC-82AB) 23981007450AS 1
U5004 23171011750AS NJM2845DL1-33 23171011750AS 1
RESISTOR GROUP
R0102 nsp RM73B--472JT+1005 00D2473010900 1
R0103 nsp RM73B--0R0KT+1005 00D2473001906 1
R0105-0108 nsp RM73B--330JT +1005 00D2473004987 4
R0109,0110 nsp RM73B--472JT+1005 00D2473010900 2
R0111 nsp RM73B--470JT +1005 00D2473005928 1
R0113 nsp RM73B--330JT +1005 00D2473004987 1
R0117 nsp RM73B--470JT +1005 00D2473005928 1
R0118 nsp RM73B--472JT+1005 00D2473010900 1
R0123 nsp RM73B--472JT+1005 00D2473010900 1
R0124,0125 nsp RM73B--472JT (1608) +1608 00D2472009909 2
R0126 nsp RM73B--472JT+1005 00D2473010900 1
R0128-0130 nsp RM73B--330JT +1005 00D2473004987 3
R0141 nsp MNR04=472(1005X4) 126210007557S 1
R0143-0146 nsp MNR04=330(1005X4) 126210002538S 4
R0149 nsp MNR04=820(1005X4) 126210003531S 1
R0150 nsp MNR04=330(1005X4) 126210002538S 1
