Denon AVR-X5200W Service Manual

Sound mode
Surround Parameter
Dialog
Enhancer
Tone
z
6
Audyssey
Restorer
z
9
Center
Spread
Center Gain
MultEQ
®
XT 32
z
7
Dunamic EQ
z
8
Dunamic
Volume
z
8
Audyssey
LFC
TMz
8
Audyssey
DSX
®
Direct/Pure Direct (2-channel)
z
4
Direct/Pure Direct (Multi-channel)
z
4
DSD Direct (2-channel)
DSD Direct (Multi-channel)
z
4
Stereo
SSSSSS S
Multi Ch In
SSSSSSS
Dolby Surround
S SSSSSS S
DTS Neo:X
SSSSSSS S
Audyssey DSX
®
SSSSSSS
Dolby Digital
SSSSSSS
Dolby Digital Plus
SSSSSSS
Dolby TrueHD
SSSSSSS
Dolby Atmos
SSSSSS
DTS Surround
SSSSSSS
DTS 96/24
SSSSSSS
DTS-HD
SSSSSSS
DTS Express
SSSSSSS
Multi Ch Stereo
SSSSSS S
Rock Arena
S
S
SSSS S
Jazz Club
SSSSSS S
Mono Movie
SSSSSS S
Video Game
SSSSSS S
Matrix
SSSSSS S
Virtual
SSSSS S
z
4,
z
6 -
z
9 : “Sound modes and surround parameters” (v p. 302)
Contents Connections Playback Settings Tips Appendix
301
Front panel Display Rear panel Remote Index
z1
This item can be selected when the Dolby Digital, Dolby Digital Plus, Dolby TrueHD or Dolby Atmos signal is played back.
z2
This item can be selected when the Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos or DTS is played back.
z3
This item can be selected when a Dolby Digital or DTS signal or DVD-Audio is played.
z4
During playback in Pure Direct mode, the surround parameters are the same as in Direct mode.
z5 This setting is available when “Subwoofer Mode” in the menu is set to “LFE+Main”. (v
p. 237)
z6 This item cannot be set when “Dynamic EQ” is set to “On”. (v
p. 182)
z7
This item cannot be set when Audyssey
®
Setup (Speaker Calibration) has not been performed.
z8
This item cannot be set when “MultEQ
®
XT32” in the menu is set to “Off”. (v p. 181)
z9
This item can be set when the input signal is analog, PCM 48 kHz or 44.1 kHz.
Contents Connections Playback Settings Tips Appendix
302
Front panel Display Rear panel Remote Index
97

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
