Denon AVR-X6200W - Page 109

The circuit around CY920 is faulty.
Can the output voltage (3.3 V) to U611
(DC-DC-Conv.) be conrmed?
Can the output voltage (1.2 V) to U608
(DC-DC Conv.) be conrmed?
Can the output voltage (2.5 V) to U6101
(DC-DC Conv.) be conrmed?
Can the output voltage (1.8 V) to U609
(DC-DC Conv.) be conrmed?
Are the versions of the Ethernet SBL and IMG displayed in Version
Check Mode?
Is E_POWER1 (U5001 uCOM 53 pin) "Hi" ?
Is E_POWER4 (U5001 uCOM 56 pin) "Hi" ?
Is E_POWER2 (U5001 uCOM 54 pin) "Hi" ?
Is E_POWER4 (U5001 uCOM 56 pin) "Hi" ?
The circuit of E_POWER1 between
U5001 and Q611 are faulty.
The circuit of E_POWER4 between
U5001 and U608 are faulty.
The circuit of E_POWER2 between
U5001 and U6101 are faulty.
The circuit of E_POWER4 between
U5001 and U609 are faulty.
The circuit around U611 (DC-DC-Conv.)
is faulty.
The circuit around U608 (DC-DC.Conv.)
is faulty.
The circuit around U6101 (DC-DC.Conv.)
is faulty.
The circuit around U609 (DC-DC.Conv.)
is faulty.
The Ethernet software is faulty.
NO
NO
NO
NONO
NO
NO
YES
YES
YES
YES
NO
YES
YES
YES
YES
YES
109
