Denon AVR-X6200W Service Manual

2. Selecting the Mode for Service-related Operations
2.1. Actions
Select diagnostic mode (service path check mode), protection history display mode, or 232C standby clear mode.
2.2. Starting up
While holding down buttons "
STATUS
" and "
ZONE3 SOURCE
" simultaneously, press the power button to turn on the
power.
Select the desired mode using the "
CURSOR
f
/
d
" button, then press the "
ENTER
" button to conrm.
2.3. Displaying and Selecting Each Mode
The information shown on the display switches each time the "
CURSOR
f
/
d
" button is pressed.
Press the "
ENTER
" button to set the currently displayed mode and restart the device.
q
FLD
L1
– 1 . S E R V I C E C H E C K
L2
2 . P R O T E C T I O N
Service Path Check Mode：
The Video and Audio paths can be checked.
This function is convenient for conrming problem paths in the product and checking
the paths after repairing.
w
FLD
L1
1 . S E R V I C E C H E C K
L2
– 2 . P R O T E C T I O N
The protection history can be checked.
e
FLD
L1
2 . P R O T E C T I O N
L2
– 3 . R S 2 3 2 C R E S E T
Switches from 232C standby mode to normal standby mode.
r
FLD
L1
3 . R S 2 3 2 C R E S E T
L2
– 4 . O P I N F O
Operation Info for the unit can be checked.
t
FLD
L1
4 . O P I N F O
L2
– 5 . T U N E R F R Q S E T
Enables reception STEP of the ANALOG TUNER to be changed.
y
FLD
L1
5 . T U N E R F R Q S E T
L2
– 6 . R E M O T E I D
This function is for operating only the desired AV receiver.
2.3. Canceling the selected mode
Press the power button to turn off the power.
24

Denon AVR-X6200W Specifications

General

Display	VFL
Product color	Silver
RS-232 ports	1
12V trigger ports quantity	2
Speakers connectivity type	RCA
HDMI in	8
Composite video in	5
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	13.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Number of HDMI outputs	3
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
3D	-
Supported graphics resolutions	4096 x 2160
Card reader integrated	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV
Image formats supported	JPG

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	167 mm
Weight	14100 g
