Denon AVR-X6200W Service Manual

DISASSEMBLY
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "Precautions During Work" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completingthe
work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FLD PCB
(Ref. No. of EXPLODED VIEW : C1)
HP PCB
(Ref. No. of EXPLODED VIEW : C2)
HDMI USB FRONT PCB
(Ref. No. of EXPLODED VIEW : B2)
TOP COVER
MAIN TRANS
See "DISASSEMBLY"
4. MAIN TRANS
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : 8)
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
AMP PCB
(Ref. No. of EXPLODED VIEW : D)
R-AMP CONNECT PCB
(Ref. No. of EXPLODED VIEW : D1)
L-AMP CONNECT PCB
(Ref. No. of EXPLODED VIEW : D2)
RADI_PROTDET2 PCB
(Ref. No. of EXPLODED VIEW : D5)
BACK PANEL ASSY
See "DISASSEMBLY"
5. BACK PANEL ASSY
and "EXPLODED VIEW"
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : A)
AUDIO/VIDEO PCB
(Ref. No. of EXPLODED VIEW : B)
DAC PCB
(Ref. No. of EXPLODED VIEW : B1)
CONNECTOR-1 PCB
(Ref. No. of EXPLODED VIEW : B4)
CONNECTOR-2 PCB
(Ref. No. of EXPLODED VIEW : B5)
CONNECTOR-3 PCB
(Ref. No. of EXPLODED VIEW : B6)
CONNECTOR-5 PCB
(Ref. No. of EXPLODED VIEW : B8)
SPEAKER PCB
(Ref. No. of EXPLODED VIEW : C)
HL SPEAKER PCB
(Ref. No. of EXPLODED VIEW : C3)
232C POHNO PCB
(Ref. No. of EXPLODED VIEW : D4)
SMPS PCB
See "DISASSEMBLY"
3. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
(Ref. No. of EXPLODED VIEW : D3)
12

Denon AVR-X6200W Specifications

General

Display	VFL
Product color	Silver
RS-232 ports	1
12V trigger ports quantity	2
Speakers connectivity type	RCA
HDMI in	8
Composite video in	5
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	13.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Number of HDMI outputs	3
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
3D	-
Supported graphics resolutions	4096 x 2160
Card reader integrated	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV
Image formats supported	JPG

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	167 mm
Weight	14100 g
