Denon AVR-X6200W Service Manual

Jump to the target of a schematic diagram
connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
• Page magnication stays the same as before the
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Read the following information before using the service manual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
You can use the search function in Acrobat Reader to
search for a Ref. No. in schematic diagrams, printed
wiring circuit diagrams, block diagrams, and parts
lists.
1. Press
Ctrl+Shift+F
on the keyboard.
• The Search window appears.
2. Enter the Ref. No. you want to search for in the
Search window, and then click the
Search
button.
• A list of search results appears.
3. Click an item on the list.
• The screen jumps to the page for that item, and the
search phrase is displayed.
Ctrl
Shift
F
3

Denon AVR-X6200W Specifications

General

Display	VFL
Product color	Silver
RS-232 ports	1
12V trigger ports quantity	2
Speakers connectivity type	RCA
HDMI in	8
Composite video in	5
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	13.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Number of HDMI outputs	3
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
3D	-
Supported graphics resolutions	4096 x 2160
Card reader integrated	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV
Image formats supported	JPG

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	167 mm
Weight	14100 g
