5. BACK PANEL ASSY
Proceeding : TOP COVER
→
FRONT PANEL ASSY
→
RADIATOR ASSY
→
SMPS ASSY
→
POWER TRANS
→
BACK PANEL ASSY
(1) Remove the screws.
Shooting
direction: D
Shooting
direction: C
↑Shooting direction: A↑
