Denon AVR-X6200W Service Manual

FIRMWARE UPDATE PROCEDURE
1. Updating via USB
The latest rmware can be downloaded to a USB memory for updates.
1.1. Connecting to the USB Memory
(1) Preparation
• Use a memory that supports USB2.0.
• USB format : Prepare a USB memory formatted in FAT16 or FAT32.
• Do not run the USB memory through a hub.
• Do not connect a computer to the USB port of this unit using a USB cable.
• Do not use an extension cable when connecting the USB unit.
• If a USB memory device cannot be updated, replace it with a different USB memory device and perform the update
again.
1.2. Unzipping the Downloaded File
Unzip the downloaded le on your computer.
AVR-XXXXXXX USB_AVR-XXXXXXX_XXXXXXXXXXXX-XXXX.zip
The "rmwares" folder is created upon unzipping the le.
Copy that folder to USB ash drive.
The "rmwares" folder must be in the root directly of the USB ash drive (memory).
copy to USB flash drive
80

Denon AVR-X6200W Specifications

General

Display	VFL
Product color	Silver
RS-232 ports	1
12V trigger ports quantity	2
Speakers connectivity type	RCA
HDMI in	8
Composite video in	5
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	13.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
Number of HDMI outputs	3
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
3D	-
Supported graphics resolutions	4096 x 2160
Card reader integrated	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV
Image formats supported	JPG

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	167 mm
Weight	14100 g
