Pin PinName Symbol I/O Pu/Pd LvCnv STBY STOP
CEC
STBY
Function
140 AVSS AVSS - - - - - - GND
141 P40/IRQ8-B/AN0 CEC_IN I SW3VPu - I I I CEC-D signal input pin
142 VREF VREF - - - - - -
Reference voltage (+3.3V) input pin for A/D
port
143 AVCC AVCC - - - - - - +3.3V
144
P05/IRQ13-A/
TMO3/RxD4/TCK
NC I M3VPu - I I I NC
