Denon AVR-X6200W - Page 177

Pin Symbol PinName I/O Pu/Pd LvCnv STBY
CEC
STBY
FUnction
79 PD7/IRQ7 NC O C - Z - NC
80 PD6/IRQ6 DACMC O C - Z L D/A converter control pin(PCM1690)
81 PD5/IRQ5 DACMD O C - Z L D/A converter control pin(PCM1690)
82 PD4/IRQ4 DACMS1 O C - Z L D/A converter control pin(PCM1690)
83 PD3/IQR3 NC O C - Z - NC
84 PD2/IRQ2 DSP1RST O C - Z L DSP(ADSP21487KSWZ-3B) reset output pin (Reset : L)
85 PD1/IRQ1 DSP1CS O C
DA
3VPu
Z L DSP control pin (ADSP21487KSWZ-3B)
86 PD0/IRQ0 DSP1FLAG0 I - Pd Z - DSP control pin (ADSP21487KSWZ-3B)
87 P47/AN007 NC O C - Z - NC
88 P46/AN006 VIN A O C - Z - COMPOSITE VIDEO SELECT IC(NJM2595)
89 P45/AN005 VIN B O C - Z - COMPOSITE VIDEO SELECT IC(NJM2595)
90 P44/AN004 VIN C O C - Z - COMPOSITE VIDEO SELECT IC(NJM2595)
91 P43/AN003 COMP SW1 O C O/ L COMPONENT VIDEO SELECT IC(NJM2586)
92 P42/AN002 COMP SW2 O C O/ L COMPONENT VIDEO SELECT IC(NJM2586)
93 P41/AN001 NC O C -
Z - NC
94 VREFL0 VREFL0 - - - - - GND
95 P40/AN000 NC O C - Z - NC
96 VREFH0 VREFH0 - - - - - +3.3V
97 AVCC0 AVCC - - - - - +3.3V
98 P07 NC O C - Z - NC
99 AVSS0 AVSS0 - - - - - GND
100 P05 TXEN O C - Z - Front HDMI INPUT (AD8195) control pin
177
