DCD-CX3
PARTS LIST OF P.W.B. UNIT
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊
Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
00D1U-3788 SACD MODULE P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 263 1205 900 PQ012FZ01ZP +C
IC102 00D 262 3591 907 BD7956FS-E2
IC103 00D 262 3402 902 BR24L32F-WE2 +C
IC104 00D 263 0615 902 BA15218F-DXE2 +C
IC105 00D 262 3082 924 BD4730G-TR
IC106 00D GEN 8305 -3 FE/BE ROM SUB ASS'Y MX29LV320CBTC-70G *
IC107 00D 262 3339 907 SN74LVC139APWR +REF
IC108 00D 262 3682 007 MN2DS0009VP *
IC109 00D 262 3594 001 64M SDRAM(TSOP)
IC110 00D 262 2641 900 SN74LV541APW-EL2 +C
IC111 00D 262 2514 901 SN74LV138APW-EL2 +C
IC112 00D 262 3594 001 64M SDRAM(TSOP)
IC113,114 00D 262 3242 900 SN74LV273APW-EL2 +REF
IC115 00D 263 0615 902 BA15218F-DXE2 +C
IC116 00D 262 3673 003 TMP86FH47ADUG-6NB9 *
IC117,118 00D 262 3627 907 TC7SZ125F(TE85L,F)
IC501 00D 262 2875 006 16M SDRAM(TSOP)-7/8 +C
IC502 00D 262 3217 003 CXD2753R +C
IC503 00D 262 2977 917 BA25BC0FP-E2
IC504 00D 262 3629 002 DXP6001AF-G
IC505 00D 262 3198 902 TC74VHC157FT-EL +REF
IC506-508 00D 262 3203 907 TC7SHU04F-TE85L +REF
IC510 00D 262 2517 908 SN74LV08APW-EL2 +REF
IC511 00M HC0 0800 5KY TC7WHU04FU TRIPLE INVERTER
IC512 00D 262 3203 907 TC7SHU04F-TE85L +REF
TR101 00D 272 0160 901 2SB1132T100Q +C
TR102,103 00D 275 0109 903 2SK3019-TL
TR104 00D 269 0229 901 DTC143TUAT106
TR105 00D 272 0160 901 2SB1132T100Q +C
TR106 00D 269 0229 901 DTC143TUAT106
TR107,108 00D 273 0487 904 2SC2412K_T146R
TR109 00D 275 0109 903 2SK3019-TL
TR110,111 00D 269 0082 902 DTC114EKT96 +C
TR112 00D 271 0259 903 2SA1162-GR(TE85L)
TR113 00D 269 0082 902 DTC114EKT96 +C
TR114 00D 273 0487 904 2SC2412K_T146R
TR115 00D 275 0109 903 2SK3019-TL
TR116 00D 274 0204 902 2SD999(CM/CL)-T1 +C
TR117 00D 272 0166 905 2SB798(DL/DK)-T1 +C
TR118 00D 273 0487 904 2SC2412K_T146R
TR119 00D 274 0204 902 2SD999(CM/CL)-T1 +C
TR120 00D 272 0166 905 2SB798(DL/DK)-T1 +C
D103,104 00D 276 0717 903 1SS355 TE-17 +C
D501 00D 276 0717 903 1SS355 TE-17 +C
