Denon DCD-CX3 - SACD Playback Waveforms; CD Playback Waveforms

73
DCD-CX3
WAVEFORMS
13 RFINP
(CX241(17))
GND ;
15 GND_D1
SACD ; DAC Test Disc
SACD Loadin
g
→Pla
y
1 FOO
2 F +
3 F -
GND ; 14 VC16
SACD Play
GND ; 14 VC16
4 TRO
5 T +
6 T -
SACD Play (INNER)
7 SPINDLE
8 FG
9 DA1
GND ; 14 VC16
SACD Search
(
INNE
R
→OUTER
)
10 SLED
11 SLED +
12 SLED -
GND ; 14 VC16
13 RFINP
(CX241(17))
CD ; TCD-784
GND ; 15 GND_D1
CD Loadin
g
→Pla
y
1 FOO
2 F +
3 F -
GND ; 14 VC16
CD Play
4 TRO
5 T +
6 T -
GND ; 14 VC16
CD Play (INNER)
7 SPINDLE
8 FG
9 DA1
GND ; 14 VC16
CD Search
(
INNE
R
→OUTER
)
10 SLED
11 SLED +
12 SLED -
GND ; 14 VC16
