Denon DCD-CX3 - Special Tapes and Gaskets; Butyl Tape List; Nitoflon Tape List; Chukoh Tape List

65
DCD-CX3
BUTYL TAPE, NITOFLON TAPE, CHUKOH TAPE and EMI GASKET
●
購入単位は 1 巻となります。使用の際は本体分解図部品表「任意事項表示欄」の指定長さにカットしてください。
●
Purchase unit is 1 volume. Please use it, cutting into the specification length of “Remarks” of “PARTS LIST OF EXPLODED
VEW” and a lower table.
●
BUTYLTAPE と NITOFLONTAPE はペア使いになります ( 一部例外あり）。分解図中 BUTYLTAPE の番号と NITOFLONTAPE
の番号が並記してある所は、貼り付けた BUTYLTAPE の表面に NITOFLONTAPE を貼ってください。
●
BUTYL TAPE and NITOFLON TAPE become pair usage. (There is an exception in part.) The place as which the number of
BUTYL TAPE and NITOFLON TAPE is filled in with the exploded view should stick NITOFLON TAPE on the surface of
stuck BUTYL TAPE.
< BUTYL TAPE >
< NITOFLON TAPE >
< CHUKOH TAPE >
< EMI GASKET >
Ref. No. nsp Part No. Part Name Remarks Q'ty New
151 nsp 00D 125 0097 008 BUTYL TAPE(W50 T2) for JP L=70 1
152 nsp 00D 125 0092 003 BUTYL TAPE(W50 T1) L=120 1
153 nsp 00D 125 0092 003 BUTYL TAPE(W50 T1) L=15 2
154 nsp 00D 125 0097 011 BUTYL TAPE(W25 T2) for JP L=60 1
155 nsp 00D 125 0097 011 BUTYL TAPE(W25 T2) for JP L=40 2
156 nsp 00D 125 0097 011 BUTYL TAPE(W25 T2) for JP L=35 1
157 nsp 00D 125 0092 016 BUTYL TAPE (W25 T1) for JP L=150 1
158 nsp 00D 125 0092 016 BUTYL TAPE (W25 T1) L=50 1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
161 nsp 00D 125 0096 009 NITOFLON TAPE(W50) for JP L=70 1
162 nsp 00D 125 0096 009 NITOFLON TAPE(W50) L=120 1
163 nsp 00D 125 0096 009 NITOFLON TAPE(W50) L=15 2
164 nsp 00D 125 0096 012 NITOFLON TAPE(W25) for JP L=60 1
165 nsp 00D 125 0096 012 NITOFLON TAPE(W25) for JP L=40 2
166 nsp 00D 125 0096 012 NITOFLON TAPE(W25) for JP L=35 1
167 nsp 00D 125 0096 012 NITOFLON TAPE(W25) for JP L=150 1
168 nsp 00D 125 0096 012 NITOFLON TAPE(W25) L=50 1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
171 nsp 00D 125 0075 020 CHUKOH TAPE(W13/T0.13) for E2 L=30 1
171 nsp 00D 125 0075 020 CHUKOH TAPE(W13/T0.13) for JP L=30 3
172 nsp 00D 125 0075 020 CHUKOH TAPE(W13/T0.13) for JP L=40 2
173 nsp 00D 125 0075 020 CHUKOH TAPE(W13/T0.13) L=60 1
174 nsp 00D 125 0075 020 CHUKOH TAPE(W13/T0.13) L=240 1
175 nsp 00D 125 0075 004 CHUKOH TAPE(W25/T0.13) for JP L=30 1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
181 nsp 00D 461 1209 005 EMI G.(SHSG050100) for E2 L=80 1
182 nsp 00D 461 1209 005 EMI G.(SHSG050100) for E2 L=20 1
