DCD-CX3
PARTS LIST OF SACD MECHANISM
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊
Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Ref. No. nsp Part No. Part Name Remarks Q'ty New
1A FGCX3 SACD/DVD MECHA UNIT 1 *
1 - MECHA BASE ASS'Y 1 *
2 00D 9KA 2A76 0 TRAY ASSY 1 *
3 nsp 00D 411 2100 205 MECHA FRAME 1 *
4 nsp 00D 9KA 2A76 1 HOUSING ASSY 1 *
5 nsp 00D 9KA 2G97 3 CAM GEAR 1 *
6 nsp 00D 424 0280 204 SLIDE CAM 1 *
7 nsp 00D 9KA 2G97 4 DOUBLE PULLY 1 *
8 00D 9KA 2A76 2 L.MOTOR ASSY 1 *
9 nsp 00D 421 0845 006 ROLLER 2 *
10 00D 9KA 2A76 3 PU-U/D-MOTOR ASSY 1 *
11 nsp 00D 9KA 2G98 5 WORM WHEEL 1 *
12 nsp 00D 431 0450 003 TRAY HOLDER L 1 *
13 nsp 00D 431 0451 109 TRAY HOLDER R 1 *
14 nsp 00D 9KA 2G96 9 BELT GEAR FRONT 1 *
15 nsp 00D 9KA 2G97 0 BELT GEAR REAR 1 *
16 00D 9KA 2G96 8 BELT FIRST 1 *
17 00D 9KA 2G97 1 BELT SECOND 1 *
18 00D 9KA 2G97 2 BELT THIRD 1 *
19 nsp 00D 9KA 2A76 4 TOP-PLATE ASSY 1 *
20 - MOTOR BRACKET ASS'Y 1 *
22 nsp 00D 412 5322 009 CAM HOLDER 1 *
24 - SW BRACKET 1 *
25 - REAR BRACKET ASS'Y 1 *
26 nsp 00D 463 0973 008 CAM SPRING 1 *
27 nsp 00D 463 0972 009 SPRING PLATE 1 *
28 nsp 00D 463 0975 006 SHAFT SPRING 6 *
30 nsp 00D 422 0681 001 ROLLER SHAFT 1 *
32 - SLIDE SHAFT 1 *
33 00D 9KA 2A69 2 TRAVERSE MECHA ASS'Y 1 *
36 00D 423 0084 009 TIMING BELT 1 *
37 nsp 00D 462 0184 001 DAMPER 3 *
38 nsp 00D 421 0846 005 O RING 2 *
39 nsp 00D 425 0262 005 STEEL BALL 1 *
40 nsp 00D 463 0976 102 BOSS SPRING 1 *
41 - 2x3CBS-B 3 *
42 - 2x4CBS-B 7
43 - 2x6CFS-B 1
44 nsp 0RD 471 3003 002 2.6x3CBS-B 2 *
45 - 2.6x5CFS-B 2 *
46 - 3x5CBS-B 18
47 - 2.6x5CBTS(S)-Z 1 *
49 nsp 00D 475 1157 059 SLIT WASHER 1.7x3.2x0.5 1
50 nsp 00D 475 1157 091 SLIT WASHER 3.1x5.4x0.5 3
51 nsp 00D 475 1190 003 SLIT WASHER 3.1x12.0x0.5 2 *
52 nsp 00D 475 1161 016 POLY WASHER 4.1x6.5x0.5 1
53 nsp 00D 476 1003 009 3E RING 1
54 - 2x6CBTS(P)-Z 1
58 00D 9KC 1H01 1 SCR-DAMPER 4
59 00D 9KC 2G08 3 DAMPER-IDLE 4
