59
DCD-CX3
CX033 nsp 00D 205 0355 033 3P KR CON BASE(L)
CX034 nsp 00D 205 0233 032 3P EH CONNECTOR BASE
CX052 nsp 00D 205 0234 057 5P EH SID CONN BASE
CX062 nsp 00D 205 0343 061 6P CONN.BASE(KR-PH)
CX082 nsp 00D 205 0355 088 8P KR CON BASE(L)
CX101 nsp 00D 205 0375 000 10P CON.BASE(KR-PH)
CX132 00D 205 1343 976 13P FFC BASE(9610SC)
CY021 nsp 00D 205 0581 085 2P VH CON BASE (Blue)
CY031 nsp 00D 205 0343 032 3P CONN.BASE(KR-PH)
CY033 nsp 00D 205 0355 033 3P KR CON BASE(L)
CY082 nsp 00D 205 0355 088 8P KR CON BASE(L)
CY131 00D 205 1343 976 13P FFC BASE(9610SC)
CY132 00D 205 1314 976 13P FFC BASE(9616SAA) *
CY251 00D 205 1365 909 25P FFC BASE(9610)SC
z F806 00D 206 1015 045 FUSE for E2
z F806 00D 206 1057 003 FUSE(ATSC 0.8AT) for JP
z F806 00D 206 1039 005 FUSE 0.63A for E3
FB101-104 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FB106 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FB801-803 00D 235 0130 903 CHIP EMIFIL(11A121) +1608
FF806 nsp 00D 202 0040 909 FUSE CLIP(TAPE)
FH806 nsp 00D 202 0040 909 FUSE CLIP(TAPE)
JK101,102 00D 204 8666 006 1P PIN JACK(BK)
JK103 00D 204 8417 006 1P PIN JACK(S-GND)
L105 00D 231 8063 009 PULSE TRANS
L801 00D 239 8019 002 LINE FILTER COIL
RL104 00D 214 0240 003 RELAY DH1U TV-3
S601-604 00D 212 5611 903 TACT SWITCH(TAPE H5)
z S801 00D 212 1176 002 POWER SWITCH (TV-5)
ST101 - STYLE PIN
ST104,105 - STYLE PIN
ST601 - STYLE PIN
ST802,803 - STYLE PIN
ST806 - STYLE PIN
z T901 00D 233 6572 006 POWER TRANS(MINI E2) for E2 *
z T901 00D 233 0721 002 POWER TRANS(MINI J) for JP *
z T901 101 010 0180 00D POWER TRANS(MINI E3) for E3 *
X101 00D 399 1043 908 C70315-33.8688-15-3.3V
AS807 - RADIATOR
AS808 - RADIATOR
nsp 0RD 471 3304 015 3X8 CBS-Z
nsp 00D 203 0386 093 1P SIN CON ASS'Y W306-W310
nsp 00D 415 0866 006 CONDENSER COVER C864,865
Ref. No. nsp Part No. Part Name Remarks Q'ty New
