BHT-604Q
8.1 BHT-604Q Specifications
8.1.1 Hardware Specifications
Power supply (main power): Rechargeable lithium-ion battery cartridge (3.7 V DC)
Dimensions (W) x (L) x (H): 63 x 209 x 46 mm
Weight: Approx. 270 g (including battery cartridge)
Ambient operating temperature -5 to 50°C
Ambient operating humidity: 20 to 80% (with no dew condensation)
Ambient operating brightness: 20 to 10000 Lx
Depth of field: 105mm, QR Code Ver.5 (37cells x 37 cells), Error-correcting level: M,
Cell pitch 0.5mm, PCS value: 0.9 min., White reflection intensity: 85% min
500 to 3,000 Lx.
Other conditions
Refer to “8.1.2 Supported Code Types” for details
Controller: CPU: 32-bit RISC
Flash memory: 16MB
Keypad: Magic keys: 6
Function keys: 16
Numerical keys etc.: 12
Display: Type: Dot-matrix, TFT liquid crystal display (LCD) with backlight
Formation: 240 dots wide by 320 dots high
Display characters:
(The following is an example)
Font size Chars x Lines Dots (W x H)
40-dot font Full-width
Half-width
6 x 8
12 x 8
40 x 40
20 x 40
30-dot font Full-width
Half-width
8 x 10
16 x 10
30 x 30
15 x 30
24-dot font Full-width
Half-width
10 x 13
20 x 13
24 x 24
12 x 24
16-dot font Full-width
Half-width
15 x 20
30 x 20
16 x 16
8 x 16
Calendar clock: Year, month, day, hour, minute, and second
Year: 2 digits
Auto leap year correction up until 2099
Indicator LED: Colors: Red, green and blue
(Note) Some of the pixels on the LCD may not illuminate or stay permanently illuminated. Furthermore,
there may also be inconsistencies in color and brightness. None of these aspects represent an
LCD defect.
Moreover, there will also be individual differences in visual quality in screens containing the above
defects.
