Denso BHT-604Q - Scanning Performance

161
2D Code Handy Terminal
8.1.3 Reading Performance
Reading Reference Position
A
s illustrated at left, align the reading window
with the center of the label (code) to be
scanned.
Reading Performance
Scanning reference position (105 mm)
Label
Field of view
at each di
stance
(W x H)
QR code cell pitch dimensions and valid scanning range
Barcode valid scanning range
