8
BHT-604Q
1.2.2 Keypad
The BHT key functions can be set at user programs.
The diagram below shows an example of settings for each key function.
②
④
⑧
⑨
①
③
⑤
⑥
⑪
⑫
⑦
⑩
⑭
⑬
NO. Key Nam
e Function and Description
(1)
Cursor key Used to move the cursor and select menus.
(2)
Magic key[M1]
(3)
Magic key[M2]
(4)
Magic key[M3]
(5)
Magic key[M4]
(6)
Magic key[M5]
(7)
Magic key[M6]
Each of the M3 and M4 keys is assigned a trigger switch by default.
The M5 key is assigned the C key by default.
Character strings can be assigned at user programs.
The SF, ENT, Backlight, MENU or C key functions can be assigned with
SYSTEM MENU.
A character or character strings can also be assigned with the user programs.
Hold down the M1 key to display the following setting screens when set to the
default.
- Beeper volume
- Vibrator
- LCD display brightness
- Power save
- Key backlight
(8) Numeric keys Used to enter data.
