BHT-805B
1.1 System Configuration
This section describes the hardware required for the barcode data collection system used by the BHT and the BHT
software.
1.1.1 Hardware Configuration
In addition to the BHT, the following hardware and software are required for the barcode data collection
system used by the BHT.
Please note that certain components of the required hardware will differ depending on the type of
communication used.
• Host computer
• CU-800 Series (option): Communication unit
• Software: BHT-BASIC 4.0 Development Pack (Option) and BHT-BASIC 4.0 Transfer Utility (Option)
Host com
p
ute
r
BHT
IrDA
communication
CU (option)
BHT-BASIC 4.0
Development Pack
(Option)
BHT-BASIC 4.0
Transfer Utility
(Option)
● : Required for system configuration
Host computer BHT CU
Wireless LAN
access point
Software Ref. Page
IrDA
communication
● ● ● — ●
Page 32
2
