8.1.2 Barcode Specifications
Supported Barcode Types
Barcode Type Bar Dimensions Read Magnification
Universal product codes
EAN-13 (JAN-13)
EAN-8 (JAN-8)
UPC-A
UPC-E
EAN-13 (JAN-13) with add-on
EAN-8 (JAN-8) with add-on
UPC-A with add-on
UPC-E with add-on
2-digit add-on
5-digit add-on
Min. 0.26 mm Min. 0.8
Interleaved 2of5 (ITF)
Standard 2of5 (STF)
Codabar (NW-7)
Code 39
Min. 0.125 mm
PCS value ≥ 0.9
Black/white bar reflection intensity difference ≥ 0.8
Min. 0.15 mm
PCS value ≥ 0.45
Code 93
Code 128, EAN-128 (GS1-128)
Min. 0.15 mm
PCS value ≥ 0.9
Black/white bar reflection intensity difference ≥ 0.8
Min. 0.19 mm
PCS value ≥ 0.45
RSS (GS1DataBar)
RSS-14 (GS1 DataBar Omnidirectional)
RSS-14 Truncated (GS1 DataBar Truncated)
RSS-14 Stacked (GS1 DataBar Stacked)
RSS-14 Stacked Omnidirectional
(GS1 DataBar Stacked Omnidirectional)
RSS Limited (GS1 DataBar Limited)
RSS Expanded (GS1 DataBar Expanded)
RSS Expanded Stacked
(GS1 DataBar Expanded Stacked)
Min. 0.15 mm
PCS value ≥ 0.9
Black/white bar reflection intensity difference ≥ 0.8
Required Optical Properties
White bars: Reflection intensity of 45% or higher
Black bars: Reflection intensity of 25% or lower
PCS value of 0.45 or higher
The reflection intensity is regulated with a light source with spectral peak of 633 nm and spectrum range of
610 to 650 nm.
