BHT-805B
8.1 BHT-805B Specifications
8.1.1 Hardware Specifications
Power supply (main power): Rechargeable lithium-ion battery cartridge (3.7 V DC)
Dimensions (W) x (L) x (H): 70 x 182 x 55 mm
Weight: Approx. 220 g (including battery cartridge BT-20LB)
Ambient operating temperature: -5 to 50° C
Ambient operating humidity: 20 to 80% (with no dew condensation)
Ambient operating brightness: 500 to 3,000 Lx.
(Depth of field: 45 mm, PCS value: 0.9 min., Reflection intensity: 85% min. for white and 5%
max. for black, Narrow bar width: min. 0.125 mm)
20 to 10,000 Lx.
(Depth of field: 100 mm, PCS value: 0.9 min., Reflection intensity: 85% min. for white and 5%
max. for black, ITF: 0.625 magnification)
Controller: CPU: 32-bit RISC
Flash memory: 32 MB
Keypad: Magic keys: 4
Function keys: 11
Numerical keys etc.: 12
Display: Type: Dot-matrix, TFT liquid crystal display (LCD) with backlight
Formation: 240 dots wide by 320 dots high
Font size Chars x Lines Dots ( W x H )
Full-width 6 x 8 40 x 40 40-dot font
Half-width 12 x 8 20 x 40
Full-width 8 x 10 30 x 30 30-dot font
Half-width 16 x 10 15 x 30
Full-width 10 x 13 24 x 24 24-dot font
Half-width 20 x 13 12 x 24
Full-width 15 x 20 16 x 16 16-dot font
Half-width 30 x 20 8 x 16
Calendar clock: Year, month, day, hour, minute, and second
Year: 2 digits
Auto leap year correction up until 2099
Indicator LED: Colors : Red, green and blue
(Note) Some of the pixels on the LCD may not illuminate or stay permanently illuminated. Furthermore,
there may also be inconsistencies in color and brightness. None of these aspects represent an
LCD defect.
Moreover, there will also be individual differences in visual quality in screens containing the above
defects.
