Barcode
*
1
Under the following conditions:
- Ambient illuminance: 500 Lx. (Xenon arc lamp)
- Code 39, 4 digits
Narrow bar: Wide bar = 1 : 2.5
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max
PCS value: 0.9 min.
*
2
Under the following conditions:
- Ambient illuminance: 500 Lx. (Xenon arc lamp)
- EAN-13
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max.
- 1.0 magnification, PCS value: 0.9 min.
*
3
Under the following conditions:
- Ambient illuminance: 500 Lx. (Xenon arc lamp)
- ITF conforming to the UPC Shipping Container Code
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max.
- 1.0 magnifications, PCS value: 0.9 min.
*
4
Under the following conditions:
- Ambient illuminance: 500 Lx. (Xenon arc lamp)
- Logistics ITF conforming to the UPS shipping Container
Code.
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max.
- 1 magnification, PCS value: 0.9 min.
*5 Under the following conditions:
- Ambient illuminance: 500 Lx. (fluorescent lamp)
- Logistics ITF conforming to the UPS shipping Containe
r
Code.
- Reflection intensity of white bars: 85% min.
Reflection intensity of black bars: 5% max
- 1.2 magnification
157
