XL™ Series Logging Options 15-5
PC Interface View Built In Display Screen
Ext. Days To Fill Memory: XXX Not Available in Built In Menu
This is a status screen that shows the number of days it would take to fill the internal data
memory card with data based on the current system configuration.
PC Interface View Built In Display Screen
S - Source
Source 1 [Date ]->
This selects what input will be used to provide data for the selected column. The selected
column is indicated by the brackets ‘[xx]’ around the column number when using the PC menu.
Source options included are Date, Time, Stage, Temp, Batt, SDI-12 inputs, etc. If “None” is
selected as the source, the selected column and all subsequent columns will be disabled. When
changing this option use the Up and Down arrow keys to move through the valid options.
Available options are listed below.
None The column is turned off, and all following columns are ignored.
Date Place the current Date in the column.
Time Place the current Time in the column.
Stage Place the Stage reading in the column. (H-350XL™ Model only)
PSI Place the PSI reading in the column. (H-350XL™ Model only)
PtTemp Place the Temperature reading in the column. (H-350XL™ Model only)
RemStg Place the Remote Stage reading in the column.
Counts Place the summation count value in the column.
TotCnt Place the total counts value in the column.
CtRate Place the counter rate value in the column.
AnaX Place analog X value in the column (there are 4 analog channels).
DigI/OX Place digital I/O X value in the column (there are 2 digital I/O ports).
Freq Place the Frequency value in the column.
Encodr Place the encoder value in the column.
Batt Place the Battery reading in the column.
TScans Place the total number of scans in the column.
BasicX Place the XL-Basic reading in the column (valid X is 1 - 5).
SDIAP Place the selected SDI-12 reading in the column (valid AP is 01 - 99).
Note the SDI-12 entries go from address 0 to 9. The parameter is always 1 to 9.
The entry SDI62 would indicate the sensor at address 6 and use the 2 parameter.
nd
FNTXX Place the selected user defined math function result in the column (01 - 40).
Note there are 40 user definable math functions that can be used for advanced
operations. Selecting a math function as a report column source will cause that
