15-6 Logging Options XL™ Series
function to be analyzed and the results logged to that column. See a later section
for a detailed description of the math operations.
SITE_ID The 8 character site id is placed in the data file.
When the XL™ turns on to scan the connected sensors and log data, it looks at the selections in
these columns to see exactly which sensors to scan and log. As soon as it comes to a column
source defined as “None” it stops the logging process and moves to the next task.
The default source values for the different XL series products is listed in the table below. In
many cases the default values will be what is needed for the user application and no changes will
be needed.
Column H-350XL H-500XL / H-522 / H-522P H-510XL
1 Date Date Date
2 Time Time Time
3 Stage Batt Stage
4 PtTemp None Batt
5 Batt None None
6 to 25 None None None
