Desoutter CVI3 Vision Installation And Upgrades

- 42 - 6159924330 - 08/2020
eBUS cable connection and termination plug
1. Plug the eBUS cable to the accessory.
2. Put the termination plug into place as shown below when the accessory is unique on the eBUS network or
when the accessory is the last one.
Socket tray
1
2
Bit tray
1
2
Stacklight
1
2
Operator panel
1
2
IO expander
