Delta 6D/7D - Quick Test Setup
In both the above cases, the following screen is displayed:
Scroll the parameters by means of the UP/DOWN keys; then click on Enter to edit.
14.1.1 Timeout
The “Timeout” defines the end of the
test. When the torque goes and
remains below the transducer minimum
load (that is normally the 10% of the
transducer full scale) for the given
timeout, the test ends.
NOTE: The “Timeout” can be
set from 100 ms up to 5000 ms.
The default value is 100 ms.
Timeout
Time
Timeout
Transducer
full scale
Transducer
min. load
The test ends
when torque
remains under
the transducer
minimum load
for the timeout
Torque
