7 USE OF DELTA 1D
The Delta 1D gives a Demo Mode and a menu for testing nutrunners, pulse tools and wrenches.
For the Delta 1D model:
 Test of tools and wrenches are executed directly from the main menu; this version does not
support the Pset definition by DeltaQC software.
 Network port is disabled.
 Curves are not created.
 Statistic Control and Cm-Cmk are not available.
The main menu is as follows:
Measurement
This option conducts a test by means of a wrench or a tool, or a free test.
Measurement
Setup
This option defines the setup parameters for the click-wrenches test,
nutrunners test, peak test, and pulse tools test. Furthermore it allows to
choose the measurement unit for the demo mode.
Settings
This menu allows to customize the Delta settings.
Refer to the paragraph “Delta 1D Settings” for further details.
Transducer
This function shows the details of the transducer connected to the Delta.
Refer to the paragraph “Transducers” for further details.
Results
It shows the results coming from the click-wrenches test, nutrunners test,
peak test, pulse tools test preload pulse tools tests.
