The measurement unit is Newton (N). In addition, the following fields are shown:
Screw lubricant – tightening counter: This field counts the number of tightenings performed by
the transducer connected to the Delta
Screw – tightening counter: This field indicates when it is necessary to replace the DLT screw
(see DLT Product Instructions for details)
Lead screw – tightening counter: This field indicates when it is necessary to replace the DLT
lead screw (see DLT Product Instructions for details).
The commands on the top of the report window provide functions either to print the report or to export
it in an Excel or PDF file.
It is also possible to connect the following analog transducers through a proper adapter:
- ART
- CMD
- GSE
- ST 4000
- Custom transducers, torque or torque/angle
(Sensitivity range 0.4 mV/V to 2.5 mV/V, bridge resistance
350 to 1000 Ohm. For transducers with encoder, the input
current must be less than 150 mA with +5V power
supply).
