DeVilbiss Drive 1025DS - General Information; Introduction and Purpose; Symbol Definitions; Important Safety Safeguards

3
LT-2329
INTRODUCTION
This service manual was designed to provide DeVilbiss Healthcare qualied service technicians and homecare providers with the proper maintenance, service, safety,
and repair procedures for the Drive DeVilbiss Oxygen Concentrator.
Read and understand all the information contained in this service manual before attempting to operate or perform any maintenance on the concentrator.
An oxygen concentrator is a device that delivers highly concentrated oxygen for therapeutic applications.
Room air is a mixture of 78% nitrogen, 21% oxygen, 1% argon and other gases. The concentrator draws in room air, separates the nitrogen from the oxygen, and
delivers concentrated oxygen to the patient through an oxygen port.
For more in-depth classroom type training, contact the Respiratory Technical Service Department at 1-800-338-1988 (814-443-4881).
NOTE– DeVilbiss reserves the right to alter or change the design of the Drive DeVilbiss Oxygen Concentrator series. Hence, slight differences in construction or
components may exist between the unit in hand and what is described in this manual.
SYMBOL DEFINITIONS
It is mandatory to read and understand the operating
instructions prior to use.
This symbol has a blue background on the
product label.
O
I
Off
On
Catalog Number LOT Number
Electric Shock Hazard. Cabinet to be removed by
authorized personnel only.
This symbol has a yellow background on the
product label.
Reset Serial Number Manufacturer
Danger - No smoking near patient or device.
This symbol has a red circle and diagonal bar on
the product label.
Alternating Current Normal Oxygen
EC REP
European
Representative
Use no Oil, Grease or Lubricants
This symbol has a red circle and diagonal bar on
the product label.
Type B applied part Low Oxygen European Rep CE mark
Do not use near heat or open ames
This symbol has a red circle and diagonal bar on
the product label.
Double Insulated Service Required
10
≤
10 LPM
10
8 8
6 6
4 4
2 2
Maximum
recommended ow
rate: 10 LPM
General Warning
This symbol is used throughout this manual to
indicate hazardous situations to avoid.
Hour Meter
C US
TUV Rheinland C-US
approval mark
Important Information
This symbol is used throughout this manual to
indicate important information you should know.
+5˚C
+35˚C
Operating Temperature
Range +5 to +35˚C (+41 to
+95˚F)
TUV Rheinland Certied
approval mark
Note and Information Symbol
This symbol is used throughout this manual to
indicate notes, useful tips, recommendations and
information.
Atmospheric Pressure
Range 840 to 1010 hPa
(Approximate sea level to
5000 ft)
Inmetro approval mark
Federal (U.S.A.) law restricts this device to sale by or on the order of a physician.
IP21
Ingress Protection - Protected against nger access to hazardous parts; protected against vertically falling water drops.
This device contains electrical and/or electronic equipment that must be recycled per EU Directive 2012/19/EU- Waste Electrical and Electronic Equipment (WEEE)
IMPORTANT SAFEGUARDS
Read this entire guide before using your DeVilbiss concentrator. Important safeguards are indicated throughout this guide. Pay special attention to all safety information.
Imminently and potentially hazardous information is highlighted by these terms:
DANGER
Indicates an imminently hazardous situation which could result in death or serious injury to the user or operator if not avoided.
WARNING
Indicates a potentially hazardous situation which could result in death or serious injury to the user or operator if not avoided.
CAUTION
Indicates a potentially hazardous situation which could result in property damage, injury, or device damage if not avoided.
IMPORTANT
Indicates important information you should know.
NOTE
Indicates notes, useful tips, recommendations, and information.
