TC500 Ethernet Cabling Certifier Operation Manual
35
12. Appendix
Specifications
Length
Range: 0 to 176 m (UTP) ; 0 to 200 m (Coax)
Resolution: 0.1 m
Accuracy:
±
1.5 m
Propagation Delay
Range: 0 to 850 ns
Resolution: 1 ns
Accuracy:
±7 ns
Delay Skew
Range:
0 to 100 ns
Resolution:
1 ns
Accuracy:
±15 ns
DC Resistance
Range: 0 to 100 Ohms
Resolution:
1 Ohms
Accuracy:
±
2 Ohms
RF Frequency
Range: 1 to 250 MHz
Resolution: NEXT, Return Loss, ELFEXT 1 to 31.25 MHz: 150 kHz
RF Items
Range:
NEXT: 0 to 70 dB
Insertion Loss: 0 to 40 dB
Resolution: 0.1 dB
Accuracy:
Insertion Loss:
±
2 dB
Auto Tests
Channel and Permanent Link
Manual Tests Single Autotest Item, 10/100/1000 BASE-T BER, TONE
Network Tests
Ping
Display
3.5 inch 16M color LCD
Working Condition
Temperature: -10 to +50 ℃
Storage Condition
Temperature:
-20 to +60
℃
Weight
Main unit: 0.79 kg
Remote unit: 0.35 kg
Dimensions
Main unit(H
×
W
×
D):
222
×
108
×
57 mm
Remote unit(H
×
W
×
D):
184
×
83
×
44 mm
