DeWalt D24000 Original Instructions

29
ENGLISH
English (original instructions)
TILE SAW
D24000
Congratulations!
You have chosen a
DeWALT
tool. Years of experience, thorough product development and
innovation make
DeWALT
one of the most reliable partners for professional power toolusers.
Technical Data
D24000
Voltage V
AC
230
UK & Ireland (GB/ LX) V
AC
230/115
Type 20
Power input (QS, GB/ LX) W 1600/1500
No-load speed min
-1
4200
Cutting disc diameter mm 250
Cutting disc bore mm 25.4
Cutting disc body thickness mm 1.5
Type of cutting disc straight, non-recessed
(continuous rim)
Max. peripheral speed cutting disc min
-1
5000
Bevel settings ° 22.5/45
Max. ripping capacity mm 610
Dimensions—in use without stand - (L x W x H) mm 1270 x 892 x 580
Dimensions – in use with stand (in highest position) - (L x W x H) mm 1270 x 892 x 1395
Dimensions – in transportation mode (saw) - (L x W x H) mm 793 x 610 x 470
Dimensions – transportation mode (water pans) - (L x W x H) mm 895 x 689 x 116
Depth of cut at 90° mm 80
Nominal weight (including cutting disc) kg 36
Max. allowable weight (with cutting disc and water) kg 51
Noise values and vibration values (triax vector sum) according to EN62841-1, EN12418
L
PA
(emission sound pressure level) dB(A) 91.8
L
WA
(sound power level) dB(A) 101.5
K (uncertainty for the given sound level) dB(A) 2.5
Vibration emission value a
h
= m/s
2
4.0
Uncertainty K = m/s
2
0.5
The vibration emission level given in this information sheet has been measured in accordance
with a standardised test given in EN12418 and may be used to compare one tool with another.
It may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration emission level represents the main applications of
the tool. However if the tool is used for different applications, with different accessories or
poorly maintained, the vibration emission may differ. This may significantly increase the
exposure level over the total workingperiod.
An estimation of the level of exposure to vibration should also take into account the times
when the tool is switched off or when it is running but not actually doing the job. This
may significantly reduce the exposure level over the total workingperiod.
Identify additional safety measures to protect the operator from the effects of vibration
such as: maintain the tool and the accessories, keep the hands warm, organisation of
workpatterns.
NOTE: This device is intended for the connection to a power supply system with maximum
permissible system impedance Zmax of 0.30  at the interface point (power service box) of
user’ssupply.
The user has to ensure that this device is connected only to a power system which fulfils the
requirement above. If necessary, the user can ask the public power supply company for the
system impedance at the interfacepoint.
EC-Declaration of Conformity
Machinery Directive
Tile Saw
D24000
DeWALT
declares that these products described under Technical Data are in compliance with:
2006/42/EC, EN62841-1:2015 + AC:2015, EN12418:2000 + A1:2009, EN ISO 12100:2010.
These products also comply with Directive 2014/30/EU and 2011/65/EU. For more information,
please contact
DeWALT
at the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical file and makes this declaration
on behalf of
DeWALT
.
Markus Rompel
Vice President of Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
30.10.2020
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word. Please read the
manual and pay attention to thesesymbols.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result
in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could
result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderateinjury.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may
result in propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
General Power Tool Safety Warnings

WARNING: Read all safety warnings, instructions, illustrations and specifications
provided with this power tool. Failure to follow all instructions listed below may result
in electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) powertool.
1) Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark areas inviteaccidents.
b ) Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust
orfumes.
c ) Keep children and bystanders away while operating a power tool. Distractions can
cause you to losecontrol.
2) Electrical Safety
a ) Power tool plugs must match the outlet. Never modify the plug in any way. Do
not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce risk of electricshock.
b ) Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electricshock.
d ) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electricshock.
e ) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of electricshock.
3) Personal Safety
a ) Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personalinjury.
b ) Use personal protective equipment. Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce personalinjuries.
c ) Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that have
the switch on invitesaccidents.
d ) Remove any adjusting key or wrench before turning the power tool on. A wrench
or a key left attached to a rotating part of the power tool may result in personalinjury.
e ) Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose clothes, jewellery or long hair can be caught
in movingparts.
g ) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection can
reduce dust-relatedhazards.

DeWalt D24000 Specifications

General

Input power	1600 W
Power source	AC
Blade bore	25.4 mm
Blade diameter	250 mm
Idle speed (max)	4200 RPM
Sound pressure level	103 dB

Weight and Dimensions

Depth	860 mm
Width	690 mm
Weight	32000 g
