65
EPAD2/CPAD2/CPAD3 series modules • Technical Reference Manual • Printing version 1.0.2 • October 04, 2016
Mounting examples
The EPAD2/CPAD2/CPAD3 modules are prepared for various mounting options:
DIN rail
Cable strap
Bolt down
Stack
For the mounting option "stack":
two long M4 Allen head screws
®
are required.
Mounting examples
For the mounting option "bolt down":
two screws
with 4.2 mm diameter are required.
