Dexter Laundry V-Series Service Procedures And Parts Data

12
ANCHORS: 1/2" X 8" GRADE 5 BOLTS
HEADED BY 4" SQ. FISH PLATE OR EQUIV.
35 1/4"
30 1/4"
25"
30"
4 3/4"
16 3/4"
8"
4"
23 1/4"
3 1/2"
PEDESTAL SHOULD BE
REINFORCED WITH
MESH OR RODS.
CONCRETE PEDESTAL MOUNTING
Figure 1-1
FLOOR OUTLINE
Figure 1-2
REAR WALL
25"
24"
MACH. CLEAR
MACHINE DEPTH
MACHINE WIDTH
FLUSH WITH WALL
RESULTS IN 2"
MACHINE CLEARANCE
24"
MIN
(1 7/8" BOLT PROTRUSION)
3 1/2"
3 1/2"
SIDE
FRONT
ABOVE
FLOOR
BELOW
FLOOR
SIDE VIEW
NUT LOCKNUT
FLOOR
PEDESTAL
EXISTING
FLOOR
6" MIN
Figure 1-3
MACHINE BASE
MACHINE MOUNTING DETAIL
WASHER
HEAVY
NOT FURNISHED WITH MACHINE
4" SQUARE FISH PLATE ANCHOR BOLT W/ 1/2" X 8" GD. 5
(REINFORCED) PEDESTAL MOUNTING
BASE
MOUNTING
STEEL
(GRADE 5) 1/2" X 2" BOLT
WASHER BEVEL
28 21/32"
26"
18 lb.
